GMC BB-812-6HD 96" Manual Box & Pan Metal Finger Brake
GMC BB-812-6HD 96" Manual Box & Pan Metal Finger Brake
Location:Ontario, CA
or
Call (714) 545-0940
Equipped With
Standard Features:
Pan & Box Brakes are hand operated machines with removable fingers and a large beam opening. With this Brake, you can fabricate pans, boxes, channels, angles, and other metal working shapes.
- One Year Parts Only Warranty
- ISO 9002 certified
- 1-9/16” adjustable beam opening
- 1” beam adjustment (front and back)
- Capable of hemming light gauge material of 26 gauge or thinner
- Capable of straight bending material fully across
- Oilable bearings to maintain precision overtime
- Adjustable stop gauge is included to allow the operator to perform repeat bends
- 16 Total fingers assortment:
- 2.5”/1pc, 3”/1pc, 3.5”/1pc, 2”/2pcs, 5”/3pcs, 6”/4pcs, 12”/4pcs
- 2 - Adjustable counterweights to assist you at max capacity bends
- All steel heavy body construction with extra heavy tie rod for minimum deflection
- May require 2 or more people
- Some assembly is required
Specifications
| Manufacturer | GMC Machine Tools |
| Model | BB-812-6HD |
| Condition | New |
| Stock Number | BB812-6HD |
| Bending Capacity | 12GA (mild steel); 16GA (stainless steel); 3/16" (soft aluminum) |
| Max. Hemming Thickness | 26 GA (mild steel) |
| Max. Box Depth | 6" |
| Bending Length Capacity | 96" |
| Bending angle | 0 - 135 degrees |
| Beam Adjustment, Front and Back | 1" |
| Min. Reverse Bend | 1/2" |
| Manual Clamping | Standard |
| Beam Opening | 1 9/16" |
| Approx. Machine Weight | 2,850 lbs. |
| Overall Dimensions (approx.) | 139 x 32 x 77"H |
